Home>Products>mobile platform lift>one man mobile electric lift platform small trailing lift

English
English
  • one man mobile electric lift platform small trailing lift
  • one man mobile electric lift platform small trailing lift
  • one man mobile electric lift platform small trailing lift
  • one man mobile electric lift platform small trailing lift
  • one man mobile electric lift platform small trailing lift
  • one man mobile electric lift platform small trailing lift

one man mobile electric lift platform small trailing lift

  • mobile platform lift
  • mobile platform lift

  • China
  • CE ISO
  • One set one man mobile electric lift platform small trailing lift
  • [email protected]
  • Within 5 working days
  • paypal,UnionPay, Visa/MasterCard, Amex, Discover,T/T
  • 65
Contact NowChat Now
Shandong Loyal Lift Machinery Co.,Ltd.

Shandong Loyal Lift Machinery Co.,Ltd.China

  • Shandong Loyal Lift Machinery Co.,Ltd.2020-07-10 09:46:19
    Welcome to my shop! Glad to serve you! Please send your question!
Price Inspection Certificate Product Specifications Company Profile

Product Description

Product Description

Instructions

A. To provide good support for the four legs of platform before using.

B. Power-on, operating the elevator button above the electric control box to make the

platformup and down

C. Operating the up button to raise the lift platform. (the motor rotation is reversed when

the platform is not raised, just swap the connection sequence of power cable, the motor

can forward.)

D. It has a remote control button above the platform, standing on the platform also can make

it up and down.

E. The platform is equipped with an emergency lowering valve, which is used for the emerg- ency lowering operation with power failure. The platform can down slowly when loose the

drop handle by hand counterclockwise. The platform will stopped declining after tighten

clockwise the drop handle.

Optional configuration

A. Imported pumping and hydraulic systems

B. Optional AC 380V power or 220V, DC, diesel-powered.

C. Assisted walking device can be added

D. Countertops can extend outward

E. Electrical explosion

Others:

1. Extension board (Horizontal extension 500mm)
2. Insulation platform (Suitable for electric aerial work)
3. Explosion-proof electric parts (Suitable for aerial work on stone oil, natural gas etc)

Model

Lifting height

(m)

Loading

Capacity

(kg)

Table

Size

(mm)

Overall

Dimensions

(mm)

Weight

(kg)

Power

(kw)

Voltage
single mast
WLA0.1-6 6 100 600*600 1250*840*1850 400 1.1 220
WLA0.1-8 8 100 600*600 1350*840*1950 450 1.1 220
WLA0.1-10 10 100 600*600 1500*840*2300 500 1.5 220
double masts
WLA0.2-6 6 200 1200*600 1200*840*1980 500 1.5 220
WLA0.2-8 8 200 1400*600 1400*840*1980 600 1.5 220
WLA0.2-10 10 200 1500*600 1550*840*1980 680 1.5 220
WLA0.2-12 12 200 1550*600 1950*960*1980 750 1.5 220
WLA0.2-14 14 200 1550*600 1950*960*2300 800 1.5 220
WLA0.2-16 16 200 1550*600 2000*1020*2900 960 1.5 220

Detailed Images

Mast (Post) aerial work platform virtues:

1. Main lifting mast (post) is made of high intensity aluminium extrusions, which makes better

safety and lighter.

2. There are self-designed slide blocks between masts which makes the dynamic gap in the

smallest range and insures a better performance on stable operation. This kind of structure

is much better than other guide wheel mode aerial work platform.
3. The driving chain is double chain, industrial plate chain, which provides better capacity.
4. The guard rails are unitary model that is very easy to operate, and there are guide rails and

guide wheels between the guard rails and the platform which makes the operation smoothly

and reliable, no stuck.
5. The unitary power pack is very smart and reliable. There is also the emergency valve to drop

the platform when there is a sudden power off.
6. The control voltage is 24V to insure the operator’s safety.
7. There are also electricity leak protection switch, emergency stop valve, max-limit switch switch

etc, the buttons are also water-proof.

Features

1)Adopting high strength aluminum molding material keeps deflecting degree and swing tiny.

2)Equipped with overload safety protection device
3) Equipped with safeguard valve to avoid hydraulic pipe rupture
4)It installs the emergency manual hydraulic valve to cope with power cut.
5)It also can add stretch platform to extend to the desired place when the platform length isn’t

enough.
6)Double chains greatly improve the safety factor.
7)Adopt emergency stop button multiple safety protection measures.
8)The translatable supporting legs can ensure working dead zone minimization .
9)Tailor-made guide wheel device equipped on the mast makes lifting smooth and stable.

Packaging & Shipping

Packaging: Plywood boxes or according to your requirements

Shipping: 10 days after confirm the order

FAQ

Q: What is the delivery time for your goods?

A: it is 15days after order confirmation

-Wide chassis makes the lower part of the Equipment which can bear the load balance to enhance stability.
-355/55D625 Solid Tyre, one man mobile electric lift platform small trailing lift can keep stable not only in a variety of complex conditions but also enhance the ground friction then mobile platform lift is more stable in operation and climbing easier.
-mobile platform lift The steering system adopts double oil cylinder and Hydra steering system with 40Cr steering linkage to ensure the same direction.
-Floating leveling device will start automatically when the device encountered under the condition of uneven groundto ensure the balance of equipment one man mobile electric lift platform small trailing lift with slope of 6 degrees then strengthen the safety and adaptability.
DFGXSDFGBA
-360°continuous rotationwith 50Cr rotary support
-Emergency safety pump. mobile platform lift The operator can use emergency safety pump to fall safelywhen the equipment is working at high altitude which can not be down.
-Constant pressure pump of Danfoss USA or Rexroth Germanit avoid oil leakage caused by gear pump damage in long -term construction
-one man mobile electric lift platform small trailing lift of centralized electric control box is used to ensure the safety of equipment operation
-Ground control console and platform control console the former has a large screen display with self diagnostic screen without connected mobile platform lift to the computerthen customers can easily understand the calibration status of equipment and parameters which is convenient debugging and testing.
-Controller of IFM Germany can enhance system stability
-Turntable safety lockto avoid the damage in the transport mobile platform lift and maintenance of arm rotation
-Swing-out engine bracket - provide the world industry closest to the engine design easy maintenance and repairs.
-Glass fiber one man mobile electric lift platform small trailing lift steel cover make the whole equipment nice and durable
