Mobile Mast aluminum lift

Product Description

Aerial lift platform description:

The product has passed the CE certification. It adopts aluminum mast design which is light, flexible and reliable. It is for two persons working together in exhibition hall, warehouse, supermarket, airport, port, etc.1)The product can be powered by DC or AC according to the order.2)The external size is small after folded. It can be moved into elevator and pass ordinary door or narrow passage.3)There are two controllers for ascending and descending.

4)It has unique upper platform and lower platform design.

Aerial lift platform advantage:

Application: persons working high above the ground.
Maximum platform height available: Optional: 4-20m.
Power supply available: single phase AC power.
Walking forms available: save manpower.
Optional: self-propelled.

Functions

Model Number Max height(m) Max working height(m) Rate load(kg) Platform size (m) Power supply Power weigth (kg) Overall Dimensions (L*W*H)(m)
V/HZ (KW)
Single mast lift platform GTWY4-100 4 5.7 125 0.51*0.55 AC220/50HZ 1.1 250 1.2*0.78*1.65
GTWY6-100 6 7.8 125 0.58*0.64 AC220/50HZ 1.1 280 1.2*0.78*1.65
GTWY8-100 8 9.7 125 0.58*0.64 AC220/50HZ 1.1 300 1.3*0.85*2.02
GTWY9-100 9 10.7 125 0.58*0.64 AC220/50HZ 1.1 320 1.3*0.85*2.02
Double mast lift platform GTWY6-200s 6 7.7 200 1.16*0.54 AC220/50HZ 1.1 320 1.45*0.82*1.65
GTWY8-200s 8 9.7 200 1.26*0.54 AC220/50HZ 1.1 380 1.45*0.82*1.8
GTWY9-200s 9 10.7 200 1.36*0.54 AC220/50HZ 1.1 450 1.55*0.9*2
GTWY10-200s 10 11.7 200 1.36*0.54 AC220/50HZ 1.1 490 1.55*0.9*2
GTWY12-200s 12 13.7 200 1.46*0.54 AC220/50HZ 1.5 560 1.65*0.9*2
Self-propelled lift platform (Single mast) GTWY4-100 4 5.7 125 0.51*0.55 AC220/50HZ 0.75 185 1.05*0.88*1.70
GTWY6-100 6 7.7 125 0.65*0.61 AC220/50HZ 0.75 210 1.20*0.88*1.70
GTWY8-100 8 9.7 125 0.65*0.61 AC220/50HZ 0.75 220 1.20*0.88*1.98
Self-propelled lift platform (Double mast) GTWY6-200S 6 7.7 200 1.36*0.61 AC220/50HZ 1.5 320 1.48*0.9*2.06
GTWY7-200S 7 8.7 200 1.36*0.60 AC220/50HZ 1.5 335 1.48*0.9*2.06
GTWY8-200S 8 9.7 200 1.36*0.60 AC220/50HZ 1.5 385 1.48*0.9*2.06
GTWY9-200S 9 10.7 200 1.36*0.60 AC220/50HZ 1.5 450 1.48*0.9*2.06
GTWY10-200S 10 11.7 200 1.36*0.60 AC220/50HZ 1.5 490 1.48*0.9*2.06
GTWY12-200S 12 13.7 200 1.46*0.60 AC220/50HZ 1.5 560 1.58*0.9*2.06
Self-propelled lift platform (Three mast) GTWY13-250S 13 14.7 250 1.56*0.80 AC220/50HZ 1.5 920 1.69*1.13*2.48
GTWY14-250S 14 15.7 250 1.56*0.80 AC220/50HZ 1.5 980 1.69*1.13*2.48

Safety configuration:

1.Level gauge on chassic

2.Emergency manual descending switch

3.Antiwear polyurethane tire

4.Limit switch

5.Over load protection

6.Rubber Oil pipe:double deck steer wire

Our cetificate:

Company Information

OUR COMPANY INFORMATION

ABOUT US

Established in 2008, Suzhou Haocheng Logistics machinery is a professional manufacturer and exporter that is concerned with the design, development and production of logistics equipments . We are located in Suzhou City. Jiangsu province. China , with convenient transportation .....

OUR ADVANTAGE

We have over 48 employees, an annual sales figure that exceeds USD 8 million and are currently exporting 25% of our production worldwide. Our well-equipped facilities and excellent quality control throughout all stages of production enables us to guarantee total customer satisfaction.

OUR HONOR

As a result of our high quality products and outstanding customer service, we have gained a global sales network reaching South Korea, American ,Thailand. If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us. We are looking ....

OUR CUSTOMER AND EXHIBITION:


Hao Cheng service:

1. We supply ONE-STOP-SHOP solution service for logistics equipment.

2. We supply one year warranty and continuous parts supply

3. Company located in Suzhou,We also supply the ONE-STOP-SHOP logistics service for export business,Our nearest export port is Shanghai.



Packaging & Shipping

Model Of Packing:

Method:Pallet,Wooden Case or Nude Packing...

FAQ

FAQ:

We accept make to order,so pls tell me more detail about:

1.Max rate load(kg)

2.Max height (mm)

3.Table size (L*W)

4.Power and voltage

Contact us

-Wide chassis makes the lower part of the Equipment which can bear the load balance to enhance stability.
-355/55D625 Solid Tyre, Mobile Mast aluminum lift can keep stable not only in a variety of complex conditions but also enhance the ground friction then mobile platform lift is more stable in operation and climbing easier.
-mobile platform lift The steering system adopts double oil cylinder and Hydra steering system with 40Cr steering linkage to ensure the same direction.
-Floating leveling device will start automatically when the device encountered under the condition of uneven groundto ensure the balance of equipment Mobile Mast aluminum lift with slope of 6 degrees then strengthen the safety and adaptability.
DFGXSDFGBA
-360°continuous rotationwith 50Cr rotary support
-Emergency safety pump. mobile platform lift The operator can use emergency safety pump to fall safelywhen the equipment is working at high altitude which can not be down.
-Constant pressure pump of Danfoss USA or Rexroth Germanit avoid oil leakage caused by gear pump damage in long -term construction
-Mobile Mast aluminum lift of centralized electric control box is used to ensure the safety of equipment operation
-Ground control console and platform control console the former has a large screen display with self diagnostic screen without connected mobile platform lift to the computerthen customers can easily understand the calibration status of equipment and parameters which is convenient debugging and testing.
-Controller of IFM Germany can enhance system stability
-Turntable safety lockto avoid the damage in the transport mobile platform lift and maintenance of arm rotation
-Swing-out engine bracket - provide the world industry closest to the engine design easy maintenance and repairs.
-Glass fiber Mobile Mast aluminum lift steel cover make the whole equipment nice and durable
